It is a set that contains all the necessary elements to efficiently complete the entire SLS printing process.
1. Sinterit Lisa Pro 3D Printer
· built-in nitrogen chamber for a wider choice of materials
· possibility of using 3rd party powders
· no calibration needed after delivery
· bigger print volume: 313 mm (12.32 in) diagonally
· plug-and-play: no calibration needed
· print bed size: 150 x 200 x 260 [mm] (5.9 x 7.9 x 10.2 [in])
· XY accuracy from 0.05 [mm] (0.002 [in])
· Sinterit Sudio 2019 Open included
· Made in the Sinterit facility in Poland
General information | |
Printing technology | Selective Laser Sintering |
Printing material | Powder |
Laser system | IR Laser Diode 5 [W] ; λ =808 [nm] |
Dimensions | 690 x 500 x 880 [mm] (27.1 x 19.7 x 34.6 [in]) |
Weight | 90.0 [kg] (198 [lbs]) |
Country of origin | Poland |
Print volume | |
Max. size of print diagonally (depending on the material) | 313 mm (12.32 in) |
Flexa/TPE - high accuracy max print volume | 110x160x245 [mm] (4.33 x 6.33 x 9.65 [in]) |
PA - high accuracy max print volume | 110x160x230 [mm] (4.33 x 6.33 x 9.06 [in]) |
Printer parameters | |
Size of Print Bed | 150 x 200 x 260 [mm] (5.9 x 7.9 x 10.2 [in]) |
XY accuracy | from 0,05 [mm] (0.002 [in]) |
The layer height Z (min - max) | 0,075 - 0,175 [mm] (0.003 - 0.007 [in]) |
Power | |
Power supply | 220-240 [V] AC, 50/60 [Hz], 7 [A] or 100-130 [V] AC, 50/60 [Hz], 15 [A] |
Average power consumption | 1 [kW] |
Maximum power consumption | 1.8 [kW] |
